H5 Elite

4.5
Rated 4.5 out of 5 stars
4.5 Stars (272 Reviews)
50% Off with Code: MEMORIAL50

Premium Compact Mid-tower Case

Sale price$139.99
or
Color:White

H5 Elite
H5 Elite Sale price$139.99

Overview

The H5 Elite features a tempered glass front panel and built-in RGB functionality to showcase various lighting components. With optimized thermal performance and intuitive cable management, the H5 Elite is an ideal chassis for most builds.

  • Pre-installed fan on bottom inside panel is angled to cool GPU
  • Tempered glass front panel and built-in RGB controller
  • Perforated top panel provides optimal ventilation
  • Intuitive cable management system with wide channels, hooks, & straps
  • Tool-less access to front & side panels
  • Front panel supports 2 x 140mm fans or 280mm radiator
  • Top panel supports up to 2 x 120mm fans or 240mm radiator
  • Includes two pre-installed F140 RGB fans (Case Version) & one F120Q fan (Case Version)

Fan Capacity

Fan mounts offer space for two 140mm fans on the front panel and two 120mm fans on the top panel.

  1. Top: 2x 120mm
  2. Front: 2x 140mm / 2x 120mm
  3. Rear: 1x 120mm
  4. Bottom: 1x 120mm

Radiator Capacity

The top panel offers space for a 240mm radiator and the front panel provides room for a 280mm radiator.

Tech Specs
Key Specs
Motherboard Support
Mini-ITX, Micro-ATX, ATX
Enclosure Type
Mid-Tower
Case Material
SGCC Steel, Ultra-clear Tempered Glass, Dark Tinted Tempered Glass (Black only)
Dimensions
Height
464 mm (With Feet)
Width
227 mm
Depth
446 mm
Weight
8.1 kg
Compatibility & Clearance
Max CPU Cooler Clearance
Up to 165mm
Max GPU Clearance
Up to 365mm
Front Radiator Clearance
45mm
Cable Management
Up to 23mm
Front I/O Ports
USB 3.2 Gen 1 Type-A
1
USB 3.2 Gen 2x2 Type-C (20 Gbps)
1
Headset Audio Jack
1
Included Accessories
Installation screws
1
Cable ties
10
RGB Lighting Controller
NZXT RGB Connector: 3 (Support up to 120 LEDs)
Expansion Slots
Standard
7
Drive Bays
2.5"
1+1
3.5"
1
Fan Support
Front
2 x F Series RGB 140mm (Case Version) included
Top
2 x 120mm
Rear
1 x 120mm
Bottom
1 x F Series Quiet 120mm (Case Version) included
Filters
All Air Intakes
Radiator Support
Front
Up to 280mm
Top
Up to 240mm
Rear
Up to 120mm
Fan Specs - F140 RGB
Model
F140 RGB Fan (Case Version)
Speed
500 - 1800 RPM
Airflow
24.85 - 89.48 CFM
Static Pressure
0.94 - 3.39 mm-H2O
Noise
20 - 32.5 dBA
Fan Connector
3-pin DC
Fan Specs - F120Q
Model
F120Q Airflow Fan (Case Version)
Speed
1200 ± 240 RPM
Airflow
62.18 CFM
Static Pressure
1.05 mm-H2O
Noise
25.1 dBA
Fan Connector
3-pin DC
General
Warranty
2 Years
White Variant
Model Number
CC-H51EW-01
UPC
810074842457
EAN
5056547202372
Black Variant
Model Number
CC-H51EB-01
UPC
810074842440
EAN
5056547202365
