C850 Gold (2022)

4.8
Rated 4.8 out of 5 stars
4.8 Stars (13 Reviews)

850W Gold Fully-Modular ATX PSU

Sale price$139.99
Color:Black
Notify Me

Overview

This PSU delivers 850 watts of clean, stable power which is ideal for gaming PCs with multiple GPUs, or higher power requirements. It is also useful for SLI or Crossfire builds.

  • Modular design lets builders use only the cables they need
  • The sleeved main cables lresist heat damage as well as fraying
  • Fits any case conforming to the ATX standard
  • Supports NVIDIA GPUs up to 3090 and AMD GPUs up to RX 6900 XT
  • Zero RPM Fan mode silences the fan under low-load conditions
  • Dynamic 135mm fluid-dynamic bearing fan
  • 10-year warranty
Tech Specs
Output Connectors
24-pin ATX power
1
4+4-pin CPU power
2
6+2-pin PCIe power
6
SATA power
6
Peripherals
6
Cable Specs
24-pin ATX power
600 mm, Nylon sleeving
4+4-pin CPU power
700 mm, Nylon sleeving
6+2-pin PCIe power
650 + 150 mm, Nylon sleeving
SATA power
500 + 150 mm
Peripherals
500 + 150 mm
AC Input Rating
100 - 240Vac
10A-5A 50Hz-60Hz
DC Output Rating
+3.3V and +5V
22A (120W)
+12V
70.8A (850W)
-12V
0.3A (3.6W)
5Vsb
3A (15W)
Total
850W
Operation
PF Correction
Active @0.96
MTBF
100,000 hours
Temperature
0 - 50 °C (derating from 100% to 80% from 40 °C to 50 °C)
Energy Efficiency
Rating
80 Plus Gold
20% loading
89.71% @115Vac
50% loading
90.80% @115Vac
100% loading
88.03% @115Vac
Fan Specs
Dimensions
135 x 135 x 25 mm
Speed
0-2300 ± 10% RPM
Airflow
93.02 CFM (Tpy.)
Noise
44.5 dBA max
Bearing
Fluid Dynamic Bearing (FDB)
General
Dimensions
150 x 150 x 86mm
Material(s)
Steel, PCB and Plastic
Compliance Standard
ATX12V v2.52 / EPS12V v2.92
Regulation & Certification
cTUV-SUDus / CUL (UL60950/62368-1) / TUV / (EN60950/62368-1) / CB/ (IEC 950/62368-1) / CCC / CEC /BSMI / RCM / EAC / CE / LVD / UKCA
Warranty
10 years
Model Number
PA-8G1BB
UPC
UPC (TW)
815671017383
UPC (CN)
815671017314
UPC (AR)
815671017321
UPC (US)
815671017338
UPC (EU)
815671017345
UPC (UK)
815671017352
UPC (AU)
815671017369
UPC (JP)
815671017376
UPC (WO)
815671017406
UPC (IN)
815671017390
EAN
EAN (TW)
5060301697694
EAN (CN)
5060301697625
EAN (AR)
5060301697632
EAN (US)
5060301697649
EAN (EU)
5060301697656
EAN (UK)
5060301697663
EAN (AU)
5060301697670
EAN (JP)
5060301697687
EAN (WO)
5060301697717
EAN (IN)
5060301697700
