Large Dual-Chamber Mid-Tower ATX Airflow Case

Color:White

Overview

L'H9 Flow è un ampio case mid-tower ATX progettato per build ad alte prestazioni, bilanciando flusso d'aria ed estetica. Il suo design a doppia camera migliora il raffreddamento e la gestione dei cavi, mentre i pannelli perforati, le ventole angolate e il supporto abbondante per ventole e radiatori offrono prestazioni termiche ottimali.

  • Design a doppia camera: Separa i componenti principali dall'alimentatore e dai drive per migliorare le prestazioni termiche e la gestione dei cavi.
  • Flusso d'aria ottimizzato: Pannelli in acciaio perforato e ventole angolate frontali destre garantiscono un raffreddamento efficiente per build ad alte prestazioni.
  • Ventole preinstallate: Include tre ventole F140Q (CV) nella parte anteriore destra e una ventola F120Q (CV) nella parte posteriore. CV = Versione Case (3-pin DC)
  • Capacità di dieci ventole: Supporta fino a nove ventole da 140mm nella parte superiore, anteriore destra e inferiore, più una ventola da 120mm nella parte posteriore.
  • Vista panoramica: Mostra ogni dettaglio della tua build con pannelli in vetro temperato senza soluzione di continuità.
  • Grandi radiatori e GPU: Adatto a un radiatore fino a 420mm nella parte superiore e anteriore destra, con ampio spazio per schede grafiche di fascia alta.
  • Gestione dei cavi facile: Canali extra-larghi, cinghie in Velcro integrate e punti di fissaggio rendono il routing dei cavi senza sforzo.
  • Pronto per connessione posteriore: Compatibile con schede madri a connessione posteriore come ASUS BTF e MSI Project Zero per un aspetto senza cavi.
H9 Line up - Built to Flow. Made to Show.

COSTRUITO PER FLUIRE. FATTO PER MOSTRARE.

L'H9 Flow è un case spazioso a doppia camera progettato per build ad alte prestazioni, con ampio supporto per il raffreddamento e pannelli in vetro avvolgenti per una vista ininterrotta del tuo build.

A PC case with RGB lighting, illustrating airflow: blue arrows show cool air entering from the bottom and right, while purple arrows show warm air exiting from the top and left. Temperature display on the CPU cooler reads 32°C.

Flusso d'aria ottimizzato

Ventole angolate frontali destre e un layout ottimizzato per il flusso d'aria mantengono basse le temperature e le prestazioni stabili.

Close-up view of a black computer case with a mesh front panel showing two cooling fans inside. The case has a sleek, modern design with sharp edges and a partially visible glass side panel.

PANNELLI A RETE

Maglia ultra-fine ad alto flusso d'aria massimizza il flusso d'aria mentre filtra la polvere.

Two computer towers: one black with a transparent side panel showing fans, and one white with a clear panel revealing RGB-lit components, liquid cooling, and a digital display inside.

AMPIA DOPPIA CAMERA

Separa le fonti di calore per un flusso d'aria migliorato e una costruzione più pulita.

Side view of a PC case with labeled fan/radiator mounting locations: front (3x120mm/3x140mm), top (3x120mm/3x140mm), bottom (3x120mm/3x140mm), and rear (1x120mm/1x140mm).

10 VENTOLE

Può ospitare fino a nove ventole da 140 mm e una ventola posteriore da 120 mm.

A white gaming PC case with RGB fans and a digital display, showing interior liquid cooling tubes. Purple labels indicate maximum radiator sizes: 420 mm top/right, 120 mm rear, and 360 mm bottom.

GRANDI RADIATORI

Admite radiadores de 420 mm en la parte superior y frontal para una refrigeración flexible.

Close-up of a computers interior showing an NZXT-branded cooler with a digital display reading 32°C GPU. Purple overlay text reads Up to 435mm. Bottom right has a green label: 50 Series Ready.

GRAFICA MASSIMA

Supporta GPU fino a 435 mm, offrendo ampio spazio per schede grafiche di fascia alta.

Open white computer case showing interior with highlighted motherboard tray and cable management sections in purple gradient. Multiple cable routing channels and mounting points are visible.

CONNETTORI POSTERIORI

Compatibile con le schede madri ASUS BTF e MSI Project Zero per un aspetto senza cavi.

A black NZXT computer case with its side panel open, revealing an empty interior and highlighted mounting areas. A circular inset zooms in on an internal NZXT-branded strap.

GESTIONE DEI CAVI FACILE

Canali extra-larghi, cinghie in velcro e punti di ancoraggio semplificano l'instradamento dei cavi.

Tech Specs
DIMENSIONI
Altezza
506 mm (19,9 pollici)
Larghezza
315 mm (12,4 pollici)
Profondità
481 mm (18,9 pollici)
Volume
76,7 L
Peso
12,46 kg (27,47 lb)
GENERALE
Tipo di contenitore
Torre media
Compatibilità con scheda madre
E-ATX (fino a 277 mm), ATX, Micro-ATX, Mini-ITX
Supporto per scheda madre con collegamento posteriore (BTF, Project Zero)
Sì (ATX, Micro-ATX)
Materiali
Acciaio SGCC, vetro temperato trasparente (bianco), vetro temperato colorato (nero)
SPAZIO LIBERO
Altezza del dissipatore della CPU
165 mm
Lunghezza GPU
Fino a 459 mm (con ventole di spessore <56 mm installate nella parte anteriore destra) Fino a 410 mm (con AIO da 420 mm di spessore 56 mm e ventole installate nella parte anteriore destra)
Lunghezza della PSU
200 mm
Spessore del radiatore superiore e della ventola
Fino a 80 mm (360 mm) Fino a 62 mm (420 mm)
PORTE I/O FRONTALI
USB 3.2 Tipo A
2
USB 3.2 Gen2x2 Tipo C
1
Presa per cuffie
1
SLOT DI ESPANSIONE
Standard
7
Verticale
0
VANI UNITÀ
2,5 pollici
4+2
3,5 pollici
2
SUPPORTO PER VENTOLE
Anteriore destro
3 x 120 mm / 3 x 140 mm (3 x F140Q (CV) inclusi)
Superiore
3 x 120 mm / 3 x 140 mm
Inferiore
3 x 120 mm / 3 x 140 mm
Posteriore
1 x 120 mm (1 x F120Q (CV) incluso)
SUPPORTO PER RADIATORE
Anteriore destro
Fino a 420 mm
Superiore
Fino a 420 mm
Inferiore
Fino a 360 mm
Posteriore
Fino a 120 mm
SPECIFICHE DELLA VENTOLA
Modello
F140Q (CV)
Velocità
1 350 ± 150 giri/min
Flusso d'aria
100,25 CFM
Pressione statica
1,4 mm-H₂O
Rumorosità
22,9 dBA
Connettore della ventola
A 3 pin
Modello
F120Q (CV)
Velocità
1 350 ± 150 giri/min
Flusso d'aria
60,2 CFM
Pressione statica
1,05 mm-H₂O
Rumorosità
24,1 dBA
Connettore della ventola
A 3 pin
GARANZIA
GARANZIA
2 anni
INFORMAZIONI SUL PRODOTTO
Numero del modello
CM-H92FW-01 CM-H92FB-01
UPC
810074847841 810074847858
EAN
5056547207636 5056547207643
4.3
Rated 4.3 out of 5 stars
Based on 4 reviews
100%would recommend this product
Total 5 star reviews: 1 Total 4 star reviews: 3 Total 3 star reviews: 0 Total 2 star reviews: 0 Total 1 star reviews: 0
Product QualityRated 5.0 on a scale of 1 to 5
Value for MoneyRated 4.5 on a scale of 1 to 5
4 reviews
  • KG
    Kristoffer G.
    Verified Buyer
    I recommend this product
    Product Standouts Ease of use
    Rated 4 out of 5 stars
    Aug 8, 2025
    Great product - instructions could be better

    Very roomy case so the design is is better than the H7 I ordered for another project.

    Some minor nitpicks.

    The NZXT 420 radiator could not fit on the front but was fine on the top. The actual radiator fits but the extrusion for the hoses does not in the front position. Strange that they say 420 will fit but not their own. I used the front slot for a GPU water cooler so all is good. I also have the lighting hub but I only noticed after installing the motherboard that the tightening screws are under the motherboard so a sticker there would have helped and save time. Only last thing the motherboard screws were a bit flimsy so I used my own.

    Overall once you done the build the end result is great.

    Product QualityRated 5.0 on a scale of 1 to 5
    Value for MoneyRated 4.0 on a scale of 1 to 5
  • CB
    Christopher B.
    Verified Reviewer
    I recommend this product
    Product Standouts Great Quality, Ease of use, Design, Value for Money
    Rated 4 out of 5 stars
    Jul 28, 2025
    Beautiful case.

    Upgraded from the original H9 — and the improvements are obvious.

    Cable management was already top-tier in the previous model, but NZXT has enhanced it further. There’s noticeably more space behind the motherboard tray, and the upgraded Velcro straps are now wider and more secure.

    The case is rear motherboard compatible, which was a key selling point for me and a major step forward for future-proofing. It also supports 420mm radiators, offering more room than ever for advanced cooling setups.

    One standout improvement is the cutout at the top, which allows you to route your AIO tubes cleanly and efficiently. It’s a simple addition, but a huge win for cleaner builds and less strain on tubing.

    Build quality across the board is excellent: tool-less latches, thumb screws, removable dust filters, and magnetic panels make everything more convenient. And if you’re using NZXT RGB fans, the RGB variant of the case includes them pre-installed, which means you don’t need to buy extra fans — a huge value add.

    One drawback: Lian Li Infinity fans don’t fit properly on the rear exhaust. I saw others on Reddit grinding the fan frame to make them fit, but I wasn’t willing to do that. I ended up force-fitting the fan, which isn’t ideal due to the pressure it puts on the frame and lighting elements — but it looks clean.

    Final recommendation: NZXT should revise the rear exhaust mount to better accommodate a wider variety of fans. This issue existed in the previous H9 Flow as well — it’s…

    Product QualityRated 5.0 on a scale of 1 to 5
    Value for MoneyRated 4.0 on a scale of 1 to 5
  • RT
    Ryan T.
    Verified Buyer
    I recommend this product
    Product Standouts Great Quality
    Rated 4 out of 5 stars
    Jul 22, 2025
    Great Chassis w/ minor nit

    I understand why the buttons were moved to the bottom and love the airflow improvements that opened up. But I really miss the I/o ports and power button being more accessible. Little nit pick but everything else about this chassis is amazing.

    Product QualityRated 5.0 on a scale of 1 to 5
    Value for MoneyRated 5.0 on a scale of 1 to 5
  • CS
    craig s.
    Verified Buyer
    I recommend this product
    Product Standouts Great Quality, Value for Money, Ease of use, Design
    Rated 5 out of 5 stars
    Jun 24, 2025
    Beautiful and functional

    Case does exactly what it's designed to do, maximize airflow and look stunning. Easy to build in and cable manage.

    Product QualityRated 5.0 on a scale of 1 to 5
    Value for MoneyRated 5.0 on a scale of 1 to 5
