The NZXT H9 Flow is a white ATX case with a transparent side panel, visible front and rear cooling fans for airflow, and multiple USB ports on the bottom front edge.
The NZXT H9 Flow is a white ATX case with an angled front-right corner, dual-chamber design for better airflow, and labeled dimensions: 506mm (H) x 481mm (D) x 315mm (W).
The NZXT H9 Flow is a white ATX case with three pre-installed front fans, one rear fan, optimized airflow, and includes F140Q and F120Q three-pin DC fans. Three additional fans are placed outside the case.
The NZXT H9 Flow is a dual-chamber ATX case with labeled spots for radiators and fans, supporting up to 420 mm radiators on top and front, 360 mm on the bottom, and up to ten fans. Text reads Expansive Cooling.
The NZXT H9 Flow case features a spacious interior highlighted in purple, supporting high-performance GPUs up to 435mm for maximum graphics and optimized airflow.
The NZXT H9 Flow ATX case is shown with a dual-chamber design, clearly separating components. Arrows highlight optimized airflow for better cooling and easier cable management. Text reads: “Dual-Chamber Design. Spacious layout boosts airflow and organization.”.
The NZXT H9 Flow is a white ATX case with wraparound glass panels that reveal internal components and cooling fans; text below reads Panoramic Paneling, describing its clear view and airflow optimized for showcasing your build.
The NZXT H9 Flow, a white ATX case with its side panel open, shows a clean dual-chamber design optimized for back-connect motherboards. Purple highlights mark support zones. Text: “Back-Connect Support. Compatible with ASUS BTF and MSI Project Zero.”.
The NZXT H9 Flow is a white ATX case with purple-accented cable channels and straps, featuring a dual-chamber design for easy cable management, wide channels, built-in Velcro straps, and multiple tie-down points.
The NZXT H9 Flow is a black ATX case featuring a transparent side panel, visible cooling fans for optimized airflow, an empty interior, and convenient front panel ports.
The NZXT H9 Flow is a black ATX case with a dual-chamber design, glass panels to showcase the interior and cooling fans, and measures 506mm (height) x 481mm (depth) x 315mm (width).
The NZXT H9 Flow ATX case offers a dual-chamber design for optimized airflow, supports up to ten fans, and accommodates radiators up to 420mm (top/front), 360mm (bottom), and 120mm (rear).
The NZXT H9 Flow, a black ATX case, features three pre-installed F140Q (CV) front-right fans and one F120Q (CV) rear fan for optimized airflow. CV stands for Case Version (3-pin DC).
Close-up of the NZXT H9 Flow ATX case build, showing space for graphics cards up to 435 mm, with a “50 SERIES READY” label. Caption: “H9 Flow: Dual-chamber design optimizes airflow and supports GPUs up to 435 mm.”.
The NZXT H9 Flow is a dual-chamber ATX case featuring wraparound glass panels that showcase internal components and sleek cable management, offering a panoramic view to turn your build into a visual display.
The NZXT H9 Flow is an ATX case with a spacious dual-chamber design that separates heat-generating parts for improved airflow and easier cable management.
The NZXT H9 Flow is a black ATX case with a dual-chamber design and open side panel, optimized for back-connect motherboards. Compatible with ASUS BTF and MSI Project Zero for a clean, cable-free interior.
The NZXT H9 Flow ATX case in black with purple accents is displayed open, highlighting wide cable channels, Velcro straps, tie-down points for easy cable management, and optimized airflow among other features.

H9 Flow

4.3
Rated 4.3 out of 5 stars
4.3 Stars (15 Reviews)

Grand Boîtier ATX à Flux d'Air à Double Chambre de Taille Moyenne

Color:

Color

Overview

Le H9 Flow est un boîtier ATX mi-tour spacieux conçu pour des configurations haute performance, équilibrant flux d'air et esthétique. Son design à double chambre améliore le refroidissement et la gestion des câbles, tandis que les panneaux perforés, les ventilateurs inclinés et le support généreux pour ventilateurs et radiateurs offrent des performances thermiques optimales.

  • Conception à double chambre : Sépare les composants principaux de l'alimentation et des disques pour améliorer les performances thermiques et la gestion des câbles.
  • Flux d'air optimisé : Les panneaux en acier perforés et les ventilateurs avant-droit inclinés assurent un refroidissement efficace pour les constructions haute performance.
  • Ventilateurs préinstallés : Comprend trois ventilateurs F140Q (CV) à l'avant-droit et un ventilateur F120Q (CV) à l'arrière. CV = Version du boîtier (DC à 3 broches)
  • Capacité de dix ventilateurs : Prend en charge jusqu'à neuf ventilateurs de 140 mm sur le dessus, à l'avant-droit et en bas, plus un ventilateur de 120 mm à l'arrière.
  • Vue panoramique : Mettez en valeur chaque détail de votre construction avec des panneaux en verre trempé sans couture et enveloppants.
  • Grands radiateurs et GPU : Accueille jusqu'à un radiateur de 420 mm sur le dessus et à l'avant-droit, avec beaucoup d'espace pour les cartes graphiques haut de gamme.
  • Gestion facile des câbles : Canaux extra-larges, sangles Velcro intégrées et points d'attache facilitent le routage des câbles.
  • Prêt pour la connexion arrière : Compatible avec les cartes mères à connexion arrière comme ASUS BTF et MSI Project Zero pour un look sans câbles.
H9 Line up - Built to Flow. Made to Show.

CONÇU POUR CIRCULER. FAIT POUR MONTRER.

Le H9 Flow est un boîtier spacieux à double chambre conçu pour des configurations haute performance, offrant un support de refroidissement étendu et des panneaux en verre enveloppants pour une vue ininterrompue de votre configuration.
A PC case with RGB lighting, illustrating airflow: blue arrows show cool air entering from the bottom and right, while purple arrows show warm air exiting from the top and left. Temperature display on the CPU cooler reads 32°C.

Flux d'air optimisé

Les ventilateurs avant droits inclinés et une disposition optimisée pour le flux d'air maintiennent les températures basses et les performances stables.
Close-up view of a black computer case with a mesh front panel showing two cooling fans inside. The case has a sleek, modern design with sharp edges and a partially visible glass side panel.

PANNEAUX EN MAILLE

Maille ultra-fine à haut débit d'air maximise le flux d'air tout en filtrant la poussière.
Two computer towers: one black with a transparent side panel showing fans, and one white with a clear panel revealing RGB-lit components, liquid cooling, and a digital display inside.

CHAMBRE DOUBLE SPACIEUSE

Sépare les sources de chaleur pour un meilleur flux d'air et une construction plus propre.
Side view of a PC case with labeled fan/radiator mounting locations: front (3x120mm/3x140mm), top (3x120mm/3x140mm), bottom (3x120mm/3x140mm), and rear (1x120mm/1x140mm).

10 VENTILATEURS

Peut accueillir jusqu'à neuf ventilateurs de 140 mm et un ventilateur arrière de 120 mm.

A white gaming PC case with RGB fans and a digital display, showing interior liquid cooling tubes. Purple labels indicate maximum radiator sizes: 420 mm top/right, 120 mm rear, and 360 mm bottom.

GRANDS RADIATEURS

Prend en charge des radiateurs de 420 mm en haut et à l'avant pour un refroidissement flexible.
Close-up of a computers interior showing an NZXT-branded cooler with a digital display reading 32°C GPU. Purple overlay text reads Up to 435mm. Bottom right has a green label: 50 Series Ready.

GRAPHISMES MAXIMUM

Convient aux GPU jusqu'à 435 mm pour des graphismes de premier ordre.
Open white computer case showing interior with highlighted motherboard tray and cable management sections in purple gradient. Multiple cable routing channels and mounting points are visible.

CONNECTEURS ARRIÈRE

Compatible avec les cartes mères ASUS BTF et MSI Project Zero pour un aspect sans câbles.

A black NZXT computer case with its side panel open, revealing an empty interior and highlighted mounting areas. A circular inset zooms in on an internal NZXT-branded strap.

GESTION FACILE DES CÂBLES

Canaux extra-larges, sangles Velcro et points d'attache simplifient le routage des câbles.
Tech Specs
Hauteur
506 mm (19,9 po)
Largeur
315 mm (12,4 po)
Profondeur
481 mm (18,9 po)
Volume
76,7 L
Poids
12,46 kg (27,47 lb)
Type de boîtier
Tour moyenne
Compatibilité carte mère
E-ATX (jusqu'à 277 mm), ATX, Micro-ATX, Mini-ITX
Prise en charge des cartes mères à connecteurs arrière (BTF, Project Zero)
Oui (ATX, Micro-ATX)
Matériaux
Acier galvanisé SGCC, verre trempé clair (blanc), verre trempé fumé (noir)
Hauteur du refroidisseur CPU
165 mm
Longueur de la carte graphique
Jusqu'à 459 mm (avec des ventilateurs de moins de 56 mm d'épaisseur installés à l'avant, côté droit) Jusqu'à 410 mm (avec un refroidissement liquide tout-en-un de 420 mm et des ventilateurs de 56 mm d'épaisseur installés à l'avant, côté droit)
Longueur du bloc d’alimentation
200 mm
Épaisseur du radiateur monté en haut et des ventilateurs
Jusqu'à 80 mm (360 mm) Jusqu'à 62 mm (420 mm)
USB 3.2 Type-A
2
USB 3.2 Gen2x2 Type-C
1
Prise casque
1
Standard
7
Vertical
0
2.5"
4+2
3.5"
2
Avant-Droite
3 x 120 mm / 3 x 140 mm (3 x F140Q (CV) inclus)
Haut
3 x 120 mm / 3 x 140 mm
Bas
3 x 120 mm / 3 x 140 mm
Arrière
1 x 120 mm (1 x F120Q (CV) inclus)
Avant-Droite
Jusqu'à 420 mm
Haut
Jusqu'à 420 mm
Bas
Jusqu'à 360 mm
Arrière
Jusqu'à 120 mm
Modèle
F140Q (CV)
Vitesse
1,350 ± 150 tr/min
Débit d'air
100,25 CFM
Pression statique
1,4 mmH₂O
Niveau sonore
22,9 dBA
Connecteur de ventilateur
3 broches
Modèle
F120Q (CV)
Vitesse
1,350 ± 150 RPM
Débit d'air
60.2 CFM
Pression statique
1,05 mmH₂O
Niveau sonore
24,1 dBA
Connecteur de ventilateur
3 broches
GARANTIE
2 ans
Numéro de modèle
CM-H92FW-01 CM-H92FB-01
CUP
810074847841 810074847858
EAN
5056547207636 5056547207643
4.3
Rated 4.3 out of 5 stars
Based on 15 reviews
87%would recommend this product
Total 5 star reviews: 8 Total 4 star reviews: 5 Total 3 star reviews: 1 Total 2 star reviews: 0 Total 1 star reviews: 1
